UL180a Multi Range Timer Relay
UL180a Multi Range TimerCharacteristics：Contactor capacity: AC 220V 16AFull timing range: 24hContactor resistence: ≤50mΩInsulation resistence: ≥100mΩCoil voltage: 110,230V AC
Characteristics：
Contactor capacity: AC 220V 16A
Full timing range: 24h
Contactor resistence: ≤50mΩ
Insulation resistence: ≥100mΩ
Coil voltage: 110,230V AC
Mechanical Life:105 times
Electrical Life: 107times
Ambient Temperature: -10℃~+50℃
Dimensions(mm): 90H*65.5W*17.5D
Battery: time 70h
Minimum setting unit: 10Minutes
Set up times: 15/per times 96 times
The Gross weight | |
The dimension | 90H*65.5W*17.5D |
M.O.Q | 200pcs (Samples Excepted) |
Payment term | T/T, L/C,D/P,O.A |
Delivery time | Usually 25 days (Negotiable for different order quantity) |
Promote the products with our own brand (As one of our agents in your market) | |
Promote the products with neutral packing | |
Do OEM for you. | |
Order note
Following items should be marked when ordering:
1.Product Name, Model
2.Quantity
3.Rated voltage
